| Product Type | Covered Single Wire Ferrules |
| Standards Met | DIN 46228, CSA C22.2 No. 291-14, UL 486F, cULus 486F |
| Ferrule Type | Single Wire Standard |
| Flammability Rating | UL94-HB |
| Cover Material | Polypropylene |
| Sub Brand | Pan-Term® |
| Copper Conductor Size | 1 - 1/0 |
| Base Material | Copper |
| Pin Length (mm) | 25 |
| Maximum Copper Conductor Size (AWG) | 1 - 1/0 |
| Minimum Copper Conductor Size (AWG) | 1 - 1/0 |
| Finish/Coating | Tin-Plated |
| Color Code | Blue |
| Overall Length (mm) | 41 |
| For Use With | CT-1006, CT-3001 (CD-2001-F87), CT-3001/ST (CD-920-F87), CT-3001/CCP (CD-920-F87), CT-930LPCH (CD-920-F87) |
| Part Features | Polypropylene insulation housing conforms to DIN color requirements Meets DIN, UL and CSA standards for single wire containment Funnel entry for faster insertion and lower installed cost Designed with a seamless barrel to contain loose wire strands for superior terminations Eases insertion of wire into terminal block Suitable for limited space panel applications Multiple pin lengths available for a variety of terminal blocks |
| Part No. | FSD87-25-Q |
1 AWG Pan-Term Covered Single Wire Ferrules FSD87-25-Q
Description:
These polypropylene insulated ferrules are specifically designed for single-wire applications, providing a reliable and secure connection. With a pin length of 0.98 inches (25.0 mm), these ferrules are suitable for 1 AWG (50.0 mm²) wires, making them ideal for a variety of electrical installations.
